Description
TECHNICAL INFORMATION
APPLICATIONS
- Control lines
- Leech lines & cunninghams
- Cascading vangs
- Kite bridles
SPECIFICATIONS
| Sheave Ø (mm) | 20 |
|---|---|
| B.L. (kg) | 800 |
| M.W.L. (kg) | 300 |
| Max. Rope Ø (mm) | 6 |
| Weight (g) | 21 |
MATERIALS
BB Sheave: High compression strength acetal.
Cheeks: Toughened nylon.
Important Note-Lashing line must pass through the hub with a tight splice in the head or cross over before lashing to a fixing point.
