Description
Maximum working loads and breaking loads for blocks based on cam strengths.
Sheave Ø(mm)75 mm
Sheave Ø(in)3 in
Length (mm)143 mm
Length (in)5 5/8 in
Width (mm)66 mm
Width (in)2 5/8 in
Height (mm)141 mm
Height (in)5 9/16 in
Weight (g)485 g
Weight (oz)17 oz
Maximum line Ø(mm)14 mm
Maximum line Ø(in) 9/16 in
Maximum working load (kg)136 kg
Maximum working load (lb)300 lb
Breaking load (lb)600 lb
Breaking load (kg)272 kg
FootnoteMaximum working loads and breaking loads for blocks based on cam strengths.
