Description
The 9051 adjustable cam swivel base with 468 Micro Cam-Matic cleat provides precise cleating. The cleating angle adjusts infinitely in a 5-17 degree range up and down for optimal line lead. The 16 mm sheaves feature low-friction stainless steel ball bearings to handle high loads, ideal for controls where cleating angles change dramatically.
Sheave Ø(mm)40 mm
Sheave Ø(in)1 9/16 in
Length (mm)107 mm
Length (in)4 3/16 in
Weight (g)127 g
Weight (oz)4.5 oz
Maximum line Ø(mm)8 mm
Maximum line Ø(in)5/16 in
Fasteners (mm)6 FH mm
Fasteners (in)1/4 FH in
Fastener spacing (mm)75 mm
A (mm)30.6 mm
B (mm)59.2 mm
Maximum working load (kg)400 kg
Maximum working load (lb)880 lb
Breaking load (kg)800 kg
Breaking load (lb)1764 lb
Sheave Ø(in)1 9/16 in
Length (mm)107 mm
Length (in)4 3/16 in
Weight (g)127 g
Weight (oz)4.5 oz
Maximum line Ø(mm)8 mm
Maximum line Ø(in)5/16 in
Fasteners (mm)6 FH mm
Fasteners (in)1/4 FH in
Fastener spacing (mm)75 mm
A (mm)30.6 mm
B (mm)59.2 mm
Maximum working load (kg)400 kg
Maximum working load (lb)880 lb
Breaking load (kg)800 kg
Breaking load (lb)1764 lb
